In today's world, accurate water level monitoring is essential for flood prevention, water resource management, and environmental protection. Changes in water level and quality can occur rapidly due to weather, seasonal variation, or human activity. Our IoT sensors provide real time insight into water level and related conditions, enabling early detection and informed decision making.
Our IoT sensors continuously monitor the essential parameters required for reliable water level monitoring.
Distance / Level
Distance based level sensors provide non contact measurement of water levels in rivers, lakes, reservoirs, and tanks. This enables accurate tracking of rising and falling levels and supports early flood warning.
Barometric Pressure
Barometric pressure measurements provide environmental context for interpreting level data. Monitoring barometric pressure improves accuracy in pressure compensated level calculations and trend analysis.
Electrical Conductivity
Electrical conductivity indicates the concentration of dissolved substances in water. Monitoring conductivity supports early detection of pollution, salinity changes, or contamination events.
By combining level, pressure, and conductivity measurements, water level monitoring systems provide a complete view of changing water conditions. This enables faster response, improved safety, and more effective water management.
Based on ultrasonic time of flight measurements Accuracy: 1% or better (factory calibrated) LoRaWAN® class A 2 C alkaline batteries Resolution: 1mm Distance: 0.5-10m Target Detection: First detecable target Application: General Purpose
Based on ultrasonic time of flight measurements Accuracy: 1% or better (factory calibrated) LoRaWAN® class A 2 C alkaline batteries Resolition: 1mm Distance: 0.3-5m Target Detection: Largest adetecable target Application: Tank level, sewer system
Based on ultrasonic time of flight measurements Accuracy: 1% or better (factory calibrated) LoRaWAN® class A 2 C alkaline batteries Resolition: 1mm Distance: 0.3-5m Target Detection: Largest adetecable target Application: General purpose, Detached sensor head incl. 10m cable
Level / Pressure sensor Range: From 0 to 0 mH₂O / 0 to 1 bar, relative Resolution: 2mm Accuracy: ±0.5% of full scale @ 20 °C Temperature Range: From -11 to +49 °C, ( do not expose to freezing temp. if sensor is in water) Resolution: 0.1 °C Accuracy: max. ±1 °C Electrical Conductivity Range: From 0 to 20 dS/m Resolution: 0.001 dS/m Accuracy: ±0.01 dS/m or ±10% (whichever is greater) " Length cable: 10m LoRaWAN® class A 2 C alkaline batteries
Distance sensor Range: From 0 to 40 m Resolution: 10 mm (single sample), 1 mm (average of N samples) Accuracy: < 2 m, ±50 mm, Nonlinearity is present below 1 m ≥ 2 m, ±1 % of distance or ±25 mm *Better accuracy is achieved by capturing N samples and evaluating statistical data, e.g. the average of N samples. LoRaWAN® class A 2 C alkaline batteries
Early Flood Detection
Real time level data supports timely warnings and proactive flood management.
Improved Water Quality Awareness
Continuous conductivity monitoring provides insight into changing water conditions.
Reliable Remote Monitoring
Sensors deliver continuous data from remote or difficult to access locations.
Reduced Operational Costs
Automated monitoring minimizes manual measurements and site visits.
Environmental Protection
Early detection of abnormal conditions helps protect ecosystems and water resources.
Data Driven Water Management
Accurate measurements support informed planning and long term resource management.
Effective water management starts with accurate level monitoring. Measure water level and quality in real time and act with confidence.
