In today's world, accurate monitoring of tank levels and liquid conditions is essential for safe storage, efficient operations, and product quality control. Unnoticed level changes, temperature deviations, or quality shifts can lead to spills, process disruptions, or compliance risks. Our IoT sensors for tank level, liquids, and temperature provide real time insight into tank conditions, enabling reliable control and proactive management.
Our IoT sensors continuously monitor the critical parameters required for effective tank monitoring.
Distance / Level
Distance based level sensors provide non contact measurement of liquid levels in tanks. This enables accurate tracking of fill levels and early detection of overfill or unexpected loss.
Pressure
Pressure based measurements deliver precise insight into liquid level and system behavior. Pressure monitoring is especially effective in closed or pressurized tanks.
Temperature
Temperature monitoring ensures liquids remain within safe and defined operating ranges. Changes in temperature can indicate process issues, spoilage risk, or equipment malfunction.
Electrical Conductivity
Electrical conductivity reflects the concentration of dissolved substances in liquids. Monitoring conductivity supports quality control and early detection of contamination or product changes.
By combining level, pressure, temperature, and conductivity measurements, tank monitoring systems provide a complete view of liquid conditions. This enables safer storage, higher efficiency, and greater operational confidence.
Based on ultrasonic time of flight measurements Accuracy: 1% or better (factory calibrated) LoRaWAN® class A 2 C alkaline batteries Resolution: 1mm Distance: 0.5-10m Target Detection: First detecable target Application: General Purpose
Based on ultrasonic time of flight measurements Accuracy: 1% or better (factory calibrated) LoRaWAN® class A 2 C alkaline batteries Resolition: 1mm Distance: 0.3-5m Target Detection: Largest adetecable target Application: Tank level, sewer system
Based on ultrasonic time of flight measurements Accuracy: 1% or better (factory calibrated) LoRaWAN® class A 2 C alkaline batteries Resolition: 1mm Distance: 0.3-5m Target Detection: Largest adetecable target Application: General purpose, Detached sensor head incl. 10m cable
Pressure sensor Piezoresistive transducer Range: From -1 to 10 bar Linearity / precision: max. ±0.15% of full scale Total error band: max. ±0.7% of full scale Temperature Range: From -40 to +110 °C Accuracy: typ. ± 2 °C Length cable: 2m Pipe thread: G1/4" LoRaWAN® class A 2 C alkaline batteries
Pressure sensor Piezoresistive transducer Range: From 0 to 1 bar, relative Linearity / precision: max. ±0.15% of full scale Total error band: max. ±0.5% of full scale Temperature Range: From -40 to +125 °C Accuracy: typ. ±2 °C Length cable: 10m LoRaWAN® class A 2 C alkaline batteries
Pressure sensor Piezoresistive transducer Range: From 0 to 1 bar, relative (other ranges on request) Linearity / precision: max. ±0.02% of full scale T otal error band: max. ±0.1% of full scale Temperature Range: From -40 to +125 °C Accuracy: max. ±0.1 °C Length cable: 10m LoRaWAN® class A 2 C alkaline batteries
Pressure Piezoresistive transducer Range: From 0 to bar, relative (other ranges on request) Linearity / precision: max. ±0.02% of full scale Total error band: max. ±0.1% of full scale Temperature Range: From -40 ro +125 °C Accuracy: max. ±0.1 °C Electrical Conductivity Range: From 0 to 20 mS/cm (other ranges on request) Accuracy: max. ±2.5% of full-scale Length Cable: 10m LoRaWAN® class A 2 C alkaline batteries
Prevent Overfill and Spills
Real time level monitoring reduces the risk of overflow and environmental incidents.
Improved Process Control
Accurate data supports stable operations and consistent product quality.
Enhanced Safety
Continuous monitoring helps detect abnormal conditions before they escalate into safety risks.
Reduced Operational Costs
Condition based monitoring minimizes manual inspections and unplanned downtime.
Quality Assurance
Conductivity and temperature data support product integrity and compliance requirements.
Data Driven Tank Management
Reliable insights support maintenance planning, inventory control, and long term asset management.
Safe and efficient tank operations start with accurate measurement. Monitor levels and liquid conditions in real time and stay in control.
